MSD 6HVC-L Ignition Controller 6631

Name: MSD 6HVC-L Ignition Controller 6631
Brand: MSD
SKU: 4017389
Price: 1124.99 CAD
Availability: InStock

$1,124.99 ea

NEWARRIVING SOONEstimated Ship Date 10/23/2023 (If Ordered Today)20 available from HOLLEY PERFORMANCE PRODUCTS as of 09/29/2023

Model: 4017389

0 reviewsWrite a Review Add to Wish List

Supplier has not provided any fitment data for this product.

CALL US
877.454.7792

Description Downloads Video Specifications Reviews (0) Product Q&A Related Products

Professional race teams have been relying on the power and endurance of our 6 HVC ignition control and will be excited to see the addition of a rev limiter! The 6 HVC-L ignition has a built-in rev limiter that will save the engine from overrev damaged caused by spins, missed shifts or driver misfortune. This means there is no need to mount an external rev control (I.e., less wiring and reduced weight)! The advanced component design and circuitry of the 6 HVC ignitions produce incredible voltage with high current output. Internally there is an efficient heat sync, solid component mounting and it's all encased in a clear epoxy. The RPM limit is adjustable with plug-in modules and the wiring is routed into NASCAR approved Deutsch style MSD connectors.

Features:

Includes built-in Fast rev limiter
Must Be Used w/HVC Coil PN[8250]
Built-in reverse polarity protection circuit
150 Millijoules Per Spark Up To 15000 RPM
550 Primary Voltage Output To Coil
Accepts breaker points/amplifier/magnetic pickup trigger inputs
Multiple sparks for 20 degrees of crankshaft rotation
6-pin Weathertight Connector; Mandatory For NASCAR Use
Clear epoxy potting compound for vibration protection
Clear base plate for easy tech inspection
No CARB Exemption Order Number

Holley Performance Emission Code 4: This part is legal for sale or use on Racing Use Only Vehicles. The following vehicles are considered Racing Use Only Vehicles: Racing Use Only Vehicles are vehicles that are used exclusively for competition that are not registered and that may never be used on the street. WARNING: It is against the law to install this part on an Emissions Controlled Vehicle

Installation Notes:

Designed for professional racing applications that demand high rpm for long periods of time

About MSD Ignition

Racers never stop experimenting as they search for every way to wring out more power or handling performance to to gain an edge over the competition. The team at MSD is no different as we strive to deliver the products you need to meet your performance goals. We continue to innovate and invent components and technology that deliver performance and reliability with products that are easy to use and install.

Over the course of 40-plus years, MSD Performance has been driving the development of innovative components that helped shape the way our cars race and perform. From super speedways to road courses, land speed racing to top fuel dragsters, and of course your traditional hot rod, MSD has provided the components to fire nearly anything in motorsports.

MSD was the first company to develop and offer the multiple sparking, capacitive discharge ignition for engines. The line of MSD 6-Series Ignitions are the most popular aftermarket ignitions in the world due to our race-proven performance on the track and our reliability on the street!

Early on, MSD focused squarely on ignition systems with revolutionary products like the multiple sparking CD ignition, timing and rev controls, billet aluminum distributors and the Pro-Mag, an incredible breakthrough in power and endurance.

Today MSD is developing electronics for your entire powertrain. The Atomic EFI systems for the LS engine platform and throttle body are now complemented with a transmission controller. Our DynaForce Starters and Alternators ensure that your engine cranks over to fire up and the Alternators keep it charged. MSD is poised to deliver components that work and communicate together to provide performance and value.

Downloads:

Download Name	File Size
6631.pdf	437.71KB
6631_info.pdf	118.52KB

Videos:

Specifications:

Emission Code	4
Part Type	Ignition Control Module
Primary Voltage	550
RPM	15000
RPM Range	15,000 RPM with 14.4 Volts
Secondary Voltage	40000
Spark duration	20 Degree Crankshaft Rotation
Spark Energy	150 mJ per spark
Spark Series Duration	20 Degree Crankshaft Rotation
Voltage	12-18 V; Negative Ground
Voltage Required	12-18 Volts, Negative Ground
WARNING CA Proposition 65	WARNING: Cancer and Reproductive Harm
Weight and Size	5.1 lbs.,8"L x 4"W x 2.25"H
